Features
FROZEN BAKE™ TECHNOLOGY
Frozen Bake™ technology cooks frozen foods faster by eliminating the need to preheat the oven for your favorite foods such as frozen pizza, lasagna, chicken nuggets, fries and pies.
HIGH SPEED COIL ELEMENTS
This coil element delivers quick, high heat for faster boiling and frying, so you can cook pasta or fry eggs in less time.
ADJUSTABLE SELF-CLEANING
Clean without harsh chemicals or special cleaners by running this high-temperature setting that automatically cleans the oven according to a preprogrammed cycle.
UPSWEPT SPILLGUARD COOKTOP
Raised edges help contain messes to make cleanup faster.
TEMPERATURE SENSOR
A built-in sensor monitors oven temperature and adjusts the cooking elements to help food bake evenly.
CLOSED DOOR BROILING
A broiling temperature management system helps prevent overheating to keep the kitchen comfortable and cool while still maintaining the optimal cooking temperature for food.
SABBATH MODE
This range is designed to meet the needs of those who are kosher and Sabbath observant. When Sabbath mode is enabled, the oven is set to remain on the "Bake" setting at a constant temperature until it's manually turned off. In addition, displays, tones and all other cooking and cleaning cycles are disabled. The oven light will also not activate when the oven door is opened and heating elements will not immediately turn on or off.
Specifications
General
Fuel Type
Electric
Installation Type
Slide-in
Color
Black
Manufacturer Color
Black
Appliance Care
Adjustable Self-Cleaning
Cooktop
Burners/Elements
4
Burners/Elements Output
• Left front: 2600 watt
• Left rear: 1500 watt
• Right front: 1500 watt
• Right rear: 2600 watt
• Left rear: 1500 watt
• Right front: 1500 watt
• Right rear: 2600 watt
Burner/Element Size
• Left front: 8"
• Left rear: 6"
• Right front: 6"
• Right rear: 8"
• Left rear: 6"
• Right front: 6"
• Right rear: 8"
Elements
Coil
Oven
Capacity (cu. ft.)
4.8 cu. ft.
Number of Ovens
Single
Features
Technologies
• Frozen Bake™ Technology
• Upswept SpillGuard™ Cooktop
• Upswept SpillGuard™ Cooktop
Control Lock
Yes
Delay Bake/Start
Yes
Oven Light
Yes
Self-Cleaning
Yes
Additional Information
• High-Speed Coil Elements
• Temperature Sensor
• Keep Warm
• Closed Door Broiling
• Removable door
• 2 standard oven racks
• Electronic touch guided controls
• Thermal oven cooking system
• Power On Indicator Light
• Metal and glass door
• Porcelain Coated Steel cooktop surface
• Audible signal
• Bake Element Power: 2400 Watts
• Broiler Element Power: 3400 Watts
• Temperature Sensor
• Keep Warm
• Closed Door Broiling
• Removable door
• 2 standard oven racks
• Electronic touch guided controls
• Thermal oven cooking system
• Power On Indicator Light
• Metal and glass door
• Porcelain Coated Steel cooktop surface
• Audible signal
• Bake Element Power: 2400 Watts
• Broiler Element Power: 3400 Watts
Drawer Features
Storage
Yes
Electrical Information
Information
• 240 V
• 60 Hz
• 40 A
• 60 Hz
• 40 A
Certifications and Approvals
ADA Compliant
Yes
Sabbath/Star-K
Yes
Dimensions
Class Width
30"
Width
29.87 inch(es) / 75.88 cm
Height
36 inch(es) / 91.44 cm
Depth (Without Handles)
28.13 inch(es) / 71.44 cm
Depth (Including Handles)
29.94 inch(es) / 76.04 cm
Additional Dimensions
• Maximum Height: 37"
• Cutout (D x H x W): 24" x 36" x 30 1/8"
• Depth With Door Open 90 Degree: 47 3/8"
• Cutout (D x H x W): 24" x 36" x 30 1/8"
• Depth With Door Open 90 Degree: 47 3/8"
Warranty
Warranty
Limited 1 Year Parts and Labor
UPC
UPC#
883049391878
