Features
NO PREHEAT MODE
Take preheating off your plate with No Preheat Mode. Simply place your food in the oven and start baking. The oven will adjust the cook time for frozen pizzas and more.
SPEEDHEAT™ BURNER
Generate the high heat needed for rapid boiling, searing and frying with multiple Power™ burners that offer up to 15,000 BTUs.
BROIL
Redefine mealtime with Broil to make crispy-melty nachos, juicy-seared meat, toasty grilled cheese and more.
GRIDDLE ZONE (GAS)
Maximize your cooking space for a variety of mealtime options with the 8,000 BTU Griddle Zone. One long, oval-shaped burner makes it easy to cook up all that delights, all at once.
Additional Features
CRISPY MODE
Dial up the crunch for an effortlessly easy crispy finish with Crispy Mode. Using high heat from both the top and bottom elements, add a crispy finish to your favorite recipes.
DISHWASHER-SAFE CAST-IRON GRATES
Wash these cast-iron grates right in the dishwasher when they get messy, thanks to a dishwasher-safe finish that makes them easy to clean.
STEAM CLEAN.
Use the Steam Clean Option to quickly and easily loosen light messes inside the oven without harsh chemicals or cleaners—just add water, run the cycle, and wipe away.
KEEP WARM SETTING
Keep dishes ready to serve while you work on the rest of the meal. This setting delivers low heat to the oven to keep prepared dishes from getting cold.
CONTROL LOCK MODE
Disable the control panel to avoid unintended use1 and easily clean the controls.
HIDDEN BAKE ELEMENT
A hidden bake element under the floor of the oven creates a smooth surface inside the oven that’s easier to clean.
DELAY START
Program the oven to start baking at a future time so you can move onto other things, and still get dinner to the table on time.
LARGE OVEN WINDOW
Keep an eye on your meal through the large oven window.
PORCELAIN ENAMEL COOKTOP
Clean up easily with a smooth, Porcelain Enamel Cooktop surface that makes it simple to wipe up cooktop spills.
GRIDDLE (SOLD SEPARATELY)
Make pancakes, grill vegetables or sear steaks with the Optional Griddle that lets you optimize your cooktop space for breakfast, lunch and dinner. Optional Griddle sold separately.
Specifications
General
Fuel Type
Natural Gas
Installation Type
Freestanding
Color
Black
Manufacturer Color
Black
Appliance Care
Steam Clean
Cooktop
Burners/Elements
5
Burners/Elements Output
• Left Front (SpeedHeat™): 15,000 BTU
• Left Rear: 9,500 BTU
• Right Front (SpeedHeat™): 15,000 BTU
• Right Rear (Simmer): 5,000 BTU
• Center Front (Oval Griddle Burner): 10,000 BTU
• Left Rear: 9,500 BTU
• Right Front (SpeedHeat™): 15,000 BTU
• Right Rear (Simmer): 5,000 BTU
• Center Front (Oval Griddle Burner): 10,000 BTU
Burners
Sealed
Other
Griddle
Oven
Capacity (cu. ft.)
5.1 cu. ft.
Number of Ovens
Single
Programs
• Audible Signal
• Bake
• Broil
• Cancel/Off
• Clock
• Control Lock
• Cook Time Indicator
• Crispy Mode
• Delay Start
• Keep Warm/Warm Hold
• No Preheat - Frozen Lasagna
• No Preheat - Frozen Pizza
• Timer
• Bake
• Broil
• Cancel/Off
• Clock
• Control Lock
• Cook Time Indicator
• Crispy Mode
• Delay Start
• Keep Warm/Warm Hold
• No Preheat - Frozen Lasagna
• No Preheat - Frozen Pizza
• Timer
Features
Technologies
• Crispy Mode — uses high heat from both top and bottom elements for a crispy finish
• No Preheat Mode (Frozen Lasagna, Frozen Pizza) — start baking frozen foods without preheating, automatically adjusts cook time
• Griddle Zone — dedicated 10,000 BTU oval burner for a griddle pan (griddle sold separately)
• SpeedHeat™ Burners — 15,000 BTU burners that boil 20% faster than the standard 9,500 BTU burner
• Steam Clean — loosens light oven messes with water, no harsh chemicals
• No Preheat Mode (Frozen Lasagna, Frozen Pizza) — start baking frozen foods without preheating, automatically adjusts cook time
• Griddle Zone — dedicated 10,000 BTU oval burner for a griddle pan (griddle sold separately)
• SpeedHeat™ Burners — 15,000 BTU burners that boil 20% faster than the standard 9,500 BTU burner
• Steam Clean — loosens light oven messes with water, no harsh chemicals
Air Fry
No
Control Lock
Yes
Convection
No
Delay Bake/Start
Yes
Digital Temperature Display
Yes
Oven Light
Yes
Self-Cleaning
Yes
Wi-Fi
No
Additional Information
• Hidden Bake Element
• Large Oven Window (Extra Large)
• Number of Oven Racks: 2
• Number of Rack Guides: 5
• Oven Rack Type: Standard
• Door Removable
• Power Outage Compatible
• Interior Color: Grey
• Broiler Location: Top Center
• Broiler Element Power: 16,500 BTU
• Bake Element Power: 16,500 BTU
• Large Oven Window (Extra Large)
• Number of Oven Racks: 2
• Number of Rack Guides: 5
• Oven Rack Type: Standard
• Door Removable
• Power Outage Compatible
• Interior Color: Grey
• Broiler Location: Top Center
• Broiler Element Power: 16,500 BTU
• Bake Element Power: 16,500 BTU
Electrical Information
Information
• Amps: 15
• Voltage: 120 V
• Frequency: 60 Hz
• Power Cord Included
• Voltage: 120 V
• Frequency: 60 Hz
• Power Cord Included
Certifications and Approvals
ADA Compliant
No
Information
UL Listed
Accessories
Optional
• Griddle (sold separately)
• Premium Range Porcelain Broiler Pan and Roasting Rack
• Premium Range Porcelain Broiler Pan and Roasting Rack
Dimensions
Class Width
30"
Width
29.88 inch(es) / 75.9 cm
Height
46.25 inch(es) / 117.48 cm
Depth (Without Handles)
22.9 inch(es) / 58.17 cm
Depth (Including Handles)
25.16 inch(es) / 63.91 cm
Weight
151.02 lb(s) / 68.5 kg
Additional Dimensions
• Cutout Width: 30.13 in
• Cutout Height: 36 in
• Cutout Depth: 24 in
• Minimum Height: 36 in
• Oven Interior (WxHxD): 25 in x 18.38 in x 19 in
• Cutout Height: 36 in
• Cutout Depth: 24 in
• Minimum Height: 36 in
• Oven Interior (WxHxD): 25 in x 18.38 in x 19 in
Shipping Dimensions
Weight
162.7 lb(s) / 73.8 kg
Warranty
Warranty
1-Year parts and labor
