Features
EASYCONVECT™ CONVERSION SYSTEM
Automatically adjusts conventional baking temperatures to their convection equivalents from the KitchenAid™ app, making it effortless to use convection with recipes of all kinds.
EVEN-HEAT™ TRUE CONVECTION
Features a unique bow-tie design with heating element and fan that provide even airflow and consistent temperatures throughout the entire oven for crisp, flaky baked goods, juicy, evenly browned roasts and flavorful, caramelized vegetables.
AQUALIFT®
Cleans your oven in less than an hour without odors and at a temperature below 200°F. This innovative system combines low heat with water to release baked-on spills.
STORAGE DRAWER
Provides a convenient storage area for frequently used pots and pans.
Specifications
General
Fuel Type
Natural Gas
Installation Type
Freestanding
Color
White
Manufacturer Color
White
Cooktop
Burners/Elements
5
Burners/Elements Output
• Center rear: 8,000 BTU
• Left front: 18,000 BTU
• Left rear: 9,500 BTU
• Right front: 15,000 BTU
• Right rear: 5,000 BTU
• Left front: 18,000 BTU
• Left rear: 9,500 BTU
• Right front: 15,000 BTU
• Right rear: 5,000 BTU
Burners
Sealed
Other
Griddle
Oven
Capacity (cu. ft.)
5.8
Number of Ovens
Single
Features
Control Lock
No
Convection
Yes
Delay Bake/Start
Yes
Digital Temperature Display
Yes
Oven Light
Yes
Additional Information
• EasyConvect™ Time and Temperature Conversion System takes the guesswork out of convection cooking
• Even-Heat™ True Convection System provides consistent heating and even cooking on both lower oven racks
• Aqualift® cleans your oven in less than an hour without odors and at a temperature below 200°F
• 2 Grates
• Storage drawer
• Even-Heat™ True Convection System provides consistent heating and even cooking on both lower oven racks
• Aqualift® cleans your oven in less than an hour without odors and at a temperature below 200°F
• 2 Grates
• Storage drawer
Drawer Features
Baking
No
Broiler
No
Storage
Yes
Warming
No
Dimensions
Class Width
30"
Width
29.87 inch(es) / 75.88 cm
Height
47.13 inch(es) / 119.7 cm
Depth (Without Handles)
25.44 inch(es) / 64.61 cm
Depth (Including Handles)
27.87 inch(es) / 70.8 cm
Additional Dimensions
• 27 7/8" (70.8 cm) max. depth with handle
• 36" (91.4 cm) cooktop height (max.) with leveling legs screwed in all the way ( Model/serial/rating plates may be rotated up from behind the control panel for viewing front the front of the range.)
• 47 1/8" (119.7 cm) overall height (max.) with leveling legs screwed in all the way ( Model/serial/rating plates may be rotated up from behind the control panel for viewing front the front of the range.)
• 29 7/8" (75.9 cm) width
• 25 7/16 (64.6 cm) depth. Back of range to front of cooktop ( Front door and drawer may extend farther forward,depending on styling.)
• 36" (91.4 cm) cooktop height (max.) with leveling legs screwed in all the way ( Model/serial/rating plates may be rotated up from behind the control panel for viewing front the front of the range.)
• 47 1/8" (119.7 cm) overall height (max.) with leveling legs screwed in all the way ( Model/serial/rating plates may be rotated up from behind the control panel for viewing front the front of the range.)
• 29 7/8" (75.9 cm) width
• 25 7/16 (64.6 cm) depth. Back of range to front of cooktop ( Front door and drawer may extend farther forward,depending on styling.)
Shipping Dimensions
Width
32 inch(es) / 81.28 cm
Height
48.75 inch(es) / 123.83 cm
Depth
29 inch(es) / 73.66 cm
Weight
200 lb(s) / 90.72 kg
Warranty
Warranty
Limited 1-Year Parts and Labor
UPC
UPC#
883049354866
