Features
EXTRA-LARGE, INTEGRATED REVERSIBLE CAST IRON GRILL/GRIDDLE
Enjoy ultimate cooking versatility. Cook up to six grilled cheeses on the industry's largest integrated griddle, and then flip it over to grill your favorite foods.
DUAL PURPOSE CENTER BURNER
Accommodate everything from grills and griddles to oversized pots with the industry's first combination oval/round burner
18,000 BTU POWER BOIL BURNER
Boil water fast with intense heat from this 18,000 BTU burner
CHEF CONNECT
Three options with a single touch. For instant convenience, choose when to automatically sync clocks and the range burners with the microwave's surface light and vent.
TRUE EUROPEAN CONVECTION
This oven features True European Convection, an advanced convection system that uses a third heating element and fan for the highest level of heat and air circulation.
Additional Features
GUARANTEED FIT
Replace your old 30" free-standing range with a new 30" slide-in model. GE slide-in ranges are guaranteed for an exact fit to make replacement easy
21,000 BTU TRI-RING BURNER
Versatile burner creates intense heat perfect for searing, frying and sautéing
Specifications
General
Fuel Type
Natural Gas
Installation Type
Slide-in
Color
Black Slate
Manufacturer Color
Black Slate
Appliance Care
• Self-Clean, Heavy-Duty Oven Racks
• Self-Clean with Steam Clean Option
• Self-Clean with Steam Clean Option
Cooktop
Burners/Elements
5
Burners/Elements Output
• Center: 8,000 BTU Dual Oval
• Right Front: 15,000 BTU
• Left Rear: 5,000 BTU Precise Simmer
• Left Front: 21,000 BTU Tri-ring Burner
• Right Rear: 9,500 BTU
• Right Front: 15,000 BTU
• Left Rear: 5,000 BTU Precise Simmer
• Left Front: 21,000 BTU Tri-ring Burner
• Right Rear: 9,500 BTU
Burners
Sealed
Oven
Capacity (cu. ft.)
• Total Capacity: 6.7
• Upper Oven: 2.4
• Lower Overn: 4.3
• Upper Oven: 2.4
• Lower Overn: 4.3
Number of Ovens
Double
Programs
• Audible Preheat Signal
• Auto Oven Shut-Off
• Auto Recipe Conversion
• Delay Bake Option
• Hi / Low Broil
• In-Oven Broiling
• Convection Bake
• Convection Roast
• Auto Oven Shut-Off
• Auto Recipe Conversion
• Delay Bake Option
• Hi / Low Broil
• In-Oven Broiling
• Convection Bake
• Convection Roast
Features
Technologies
• True European Convection
• Chef Connect
• Connected Capabilities: Amazon Alexa, DiGiorno, Drop, IFTTT, Innit, Nest, The Google Assistant
• Chef Connect
• Connected Capabilities: Amazon Alexa, DiGiorno, Drop, IFTTT, Innit, Nest, The Google Assistant
Control Lock
Yes
Convection
Yes
Delay Bake/Start
Yes
Digital Temperature Display
Yes
Oven Light
Yes
Self-Cleaning
Yes
Wi-Fi
Yes
Additional Information
• Continuous Heavy Cast Iron Grates
• Traditional upper oven
• Convection lower oven
• Electronic ignition system
• Automatic Self-Clean Oven Door Lock
• Electronic Touch
• Temperature Probe
• Traditional upper oven
• Convection lower oven
• Electronic ignition system
• Automatic Self-Clean Oven Door Lock
• Electronic Touch
• Temperature Probe
Drawer Features
Storage
Yes
Electrical Information
Information
• 120 V
• 60 Hz
• 15 A
• 60 Hz
• 15 A
Certifications and Approvals
ADA Compliant
Yes
Sabbath/Star-K
Yes
Accessories
Included
• Reversible Integrated Grill/Griddle
• LP conversion kit
• LP conversion kit
Optional
Trim Kit: JXFILLR1DD
Dimensions
Class Width
30"
Width
30 inch(es) / 76.20 cm
Height
36.5 inch(es) / 92.71 cm
Depth (Without Handles)
26.87 inch(es) / 68.26 cm
Depth (Including Handles)
29.5 inch(es) / 74.93 cm
Weight
270.99 lb(s) / 122.92 kg
Additional Dimensions
• Depth with Door Open: 43-7/8"
• Oven Interior Upper (W x H x D): 24" x 9-1/2" x 19-1/8"
• Oven Interior Lower (W x H x D): 24" x 15" x 20-5/8"
• Oven Interior Upper (W x H x D): 24" x 9-1/2" x 19-1/8"
• Oven Interior Lower (W x H x D): 24" x 15" x 20-5/8"
Shipping Dimensions
Width
32.7 inch(es) / 83.06 cm
Height
44.5 inch(es) / 113.03 cm
Depth
31.5 inch(es) / 80.01 cm
Weight
291.01 lb(s) / 132.00 kg
Warranty
Warranty
Limited 1 Year Parts and Labor
UPC
UPC#
084691827115
