Features
ACTIVE FLOOD PROTECT
An internal sensor prevents the dishwasher from overflowing, so you have peace of mind with every cycle.
PIRANHA™ HARD FOOD DISPOSER WITH REMOVABLE FILTER
To ensure consistently clean items, this stainless steel blade rotates at 3,600 RPM to pulverize food particles and helps to prevent large particles from clogging the wash arms.
DRY BOOST™ WITH FAN ASSIST
Gets hard-to-dry items up to 3 times drier than heated dry cycles *Compared to heated dry option.
Specifications
General
Type
Built-In
Color
White
Manufacturer Color
White
Place Settings
12
Tub Material
Plastic
Silence Rating
59 dB
Cycle Information
Number of Cycles
4
Wash Cycles
• Heavy wash
• Normal wash
• 1-hour wash
• Steam pre-wash
• Rinse-only
• Normal wash
• 1-hour wash
• Steam pre-wash
• Rinse-only
Options
• Dry Boost™ (High)
• Dry Boost™ (Normal)
• Wash TempBoost
• Steam
• Start/Reset
• Lock Controls
• Automatic Hot Start
• Dry Boost™ (Normal)
• Wash TempBoost
• Steam
• Start/Reset
• Lock Controls
• Automatic Hot Start
Features
Technologies
• Piranha™ Hard Food Disposer with removable filter
• Dry Boost™
• Dry Boost™
Filtration System
Yes
Silverware Basket
Yes
Additional Information
• Dispenser: Detergent and Rinse Aid
• Automatic Temperature Control
• Automatic HotStart
• Fill Level Pressure Sensor
• Active Flood Protect
• 1 "Clean" Cycle Progress Indicator
• Last Cycle Memory
• Wash System: 2-Level
• 4 Leveling Legs
• Tall Tub
• Automatic Temperature Control
• Automatic HotStart
• Fill Level Pressure Sensor
• Active Flood Protect
• 1 "Clean" Cycle Progress Indicator
• Last Cycle Memory
• Wash System: 2-Level
• 4 Leveling Legs
• Tall Tub
Electrical Information
Information
• 120V
• 60Hz
• 7.1A
• 60Hz
• 7.1A
Certifications and Approvals
Energy Star Certified
Yes
Accessories
Included
Power cord
Optional
WiFi Connect Requires part no. PBX23W00Y0
Dimensions
Class Width
24"
Width
23.75 inch(es) / 60.32 cm
Height (Min.)
33.37 inch(es) / 84.77 cm
Depth (Without Handle)
24 inch(es) / 60.96 cm
Depth (Including Handle)
24 inch(es) / 60.96 cm
Weight
55.01 lb(s) / 24.95 kg
Additional Dimensions
• Cabinet Width: 24"
• Height with Legs Extended - Maximum Height: 34 5/8"
• Height with Legs Extended - Maximum Height: 34 5/8"
Shipping Dimensions
Width
24.5 inch(es) / 62.23 cm
Height
35.8 inch(es) / 90.93 cm
Depth
26.2 inch(es) / 66.55 cm
Weight
64.99 lb(s) / 29.48 kg
Warranty
Warranty
1-Year parts and labor
UPC
UPC#
084691853282
