Features
SPACEWISE® EXPANDABLE ELEMENTS
Flexible elements expand to meet your cooking needs - big or small.
EVEN BAKING TECHNOLOGY
This latest technology ensures even baking every time.
KEEP WARM ZONE
Keep food warm until everything — and everyone — is ready.
EXTRA WIDE STORE-MORE™ STORAGE DRAWER
Our redesigned Store-More™ Storage drawer is now even wider - allowing you to store any unused oven racks or baking trays.
CLEANUP IS EASIER WITH HIDDEN BAKE
Lower heating elements are beneath the oven floor, making for a smooth surface that is easy to clean.
Specifications
General
Fuel Type
Electric
Installation Type
Freestanding
Color
White
Manufacturer Color
White
Cooktop
Burners/Elements
5
Burners/Elements Output
• Right Front Element Burner 3200 Watts
• Right Rear Element Burner 1200 Watts
• Left Front Element Burner (Small) 1400 Watts
• Left Front Element Burner (Large) 3000 Watts
• Left Rear Element Burner 1200 Watts
• Center Rear Element Burner 100 Watts
• Right Rear Element Burner 1200 Watts
• Left Front Element Burner (Small) 1400 Watts
• Left Front Element Burner (Large) 3000 Watts
• Left Rear Element Burner 1200 Watts
• Center Rear Element Burner 100 Watts
Burner/Element Size
• Right Front Element Burner Size 9"
• Right Rear Element Burner Size 6"
• Left Front Element Burner Size (Small) 6"
• Left Front Element Burner Size (Large) 9"
• Left Rear Element Burner Size 6"
• Right Rear Element Burner Size 6"
• Left Front Element Burner Size (Small) 6"
• Left Front Element Burner Size (Large) 9"
• Left Rear Element Burner Size 6"
Elements
Smoothtop
Oven
Capacity (cu. ft.)
5.3 cu.ft.
Number of Ovens
Single
Programs
• Bake
• Broil
• Broil
Features
Technologies
• EvenTemp™ Cooktop Element
• Even Baking Technology
• SpaceWise® Dual Expandable Element
• Extra Wide Store-More™ Storage Drawer
• Even Baking Technology
• SpaceWise® Dual Expandable Element
• Extra Wide Store-More™ Storage Drawer
Control Lock
Yes
Delay Bake/Start
Yes
Digital Temperature Display
Yes
Oven Light
Yes
Additional Information
• Smooth Cooking Surface
• Midnight Black Oven Interior
• Element On Indicator Light
• Hot-Surface Indicator Light
• Keep Warm Zone Light
• Main Oven: Steam Clean
• Timer
• Adjustable Volume Feedback
• Change between Continuous Bake Setting or 12-Hour Energy Saving Feature
• Bake: 2500 W
• Broil: 3000 W
• Midnight Black Oven Interior
• Element On Indicator Light
• Hot-Surface Indicator Light
• Keep Warm Zone Light
• Main Oven: Steam Clean
• Timer
• Adjustable Volume Feedback
• Change between Continuous Bake Setting or 12-Hour Energy Saving Feature
• Bake: 2500 W
• Broil: 3000 W
Drawer Features
Storage
Yes
Electrical Information
Information
• Connected Load @ 240V 12 kW
• Minimum Circuit Required 40 Amps
• Voltage Rating 240 V
• Minimum Circuit Required 40 Amps
• Voltage Rating 240 V
Certifications and Approvals
Information
• UL Listed
• RoHS
• RoHS
Dimensions
Class Width
30"
Width
30 inch(es) / 76.2 cm
Height
47.75 inch(es) / 121.29 cm
Depth (Without Handles)
26 inch(es) / 66.04 cm
Depth (Including Handles)
28.5 inch(es) / 72.39 cm
Weight
145 lb(s) / 65.77 kg
Additional Dimensions
• Depth With Door 90° Open 47 5/16"
• Oven Interior Height 18 1/8"
• Oven Interior Width 25 3/16"
• Oven Interior Depth 19 7/8"
• Oven Interior Height 18 1/8"
• Oven Interior Width 25 3/16"
• Oven Interior Depth 19 7/8"
Warranty
Warranty
1 Year Parts and Labor
