Features
HIGH-POWERED BTU BURNERS (18,000 BTU)
The high-powered 18,000 BTU burner provides fast, intense heat for creating large family meals and restaurant-quality dishes.
STORAGE SPACE
The storage drawer provides additional storage space for cooking trays and other kitchen utensils.
COMMERCIAL CONVECTION FAN
The convection fan provides controlled heat distribution for fast and efficient cooking.
EVEN HEAT BROILER
Reflective gas tube broiler distributes heat evenly to sear your food and seal in the juices.
CONTINUOUS CAST-IRON GRATES
Heavy-duty grates provide a seamless surface for easy pan movement and pro-style durability.
PORCELAIN SPILL TRAY
Single-piece black porcelain spill tray catches the mess and makes cleanup easy.
PORCELAIN INTERIORS
The gray porcelain oven interior adds a stylish touch and is easy to clean.
GRIDDLE FEATURE (15,000 BTU)
The 15,000 BTU griddle offers additional cooking space and flexibility.
PRO-STYLE KNOBS - LRG4807ULP
Black ABS burner control knobs add style to the bold range design.
Specifications
General
Fuel Type
Dual Fuel - Liquid Propane
Installation Type
Freestanding
Color
Stainless Steel
Manufacturer Color
Stainless Steel
Cooktop
Burners/Elements
6
Burners/Elements Output
• [1] Front Left (Single) Burner: 12,000 BTU
• [2] Front Middle (Single) Burner: 18,000 BTU
• [3] Front Right (Single) Burner: 12,000 BTU
• [4] Rear Left (Single) Burner: 12,000 BTU
• [5] Rear Middle (Single) Burner: 12,000 BTU
• [6] Rear Right (Single) Burner: 12,000 BTU
• [7] Griddle Burner: 15,000 BTU
• Tube Broil Burner: 10,000 BTU
• U-Shape Burner (30" Oven): 22,000 BTU
• Tube Burner (18" Oven): 14,000 BTU
• [2] Front Middle (Single) Burner: 18,000 BTU
• [3] Front Right (Single) Burner: 12,000 BTU
• [4] Rear Left (Single) Burner: 12,000 BTU
• [5] Rear Middle (Single) Burner: 12,000 BTU
• [6] Rear Right (Single) Burner: 12,000 BTU
• [7] Griddle Burner: 15,000 BTU
• Tube Broil Burner: 10,000 BTU
• U-Shape Burner (30" Oven): 22,000 BTU
• Tube Burner (18" Oven): 14,000 BTU
Oven
Capacity (cu. ft.)
Dual ovens at 4.6 cu. ft. and 2.2 cu. ft. capacity allows you to cook multiple dishes at a time.
Number of Ovens
Double
Electrical Information
Information
• Electrical Requirements: 120 V
• Circuit Breaker: 15 A
• Frequency: 60 Hz
• Circuit Breaker: 15 A
• Frequency: 60 Hz
Accessories
Optional
• Liquid Propane Gas Conversion Kit: LPKLRG4807U
• Wok Ring: WK01
• Bamboo Cutting Board: CB0001
• Cast Iron Reversible Griddle: RG1022
• Wok Ring: WK01
• Bamboo Cutting Board: CB0001
• Cast Iron Reversible Griddle: RG1022
Dimensions
Class Width
48"
Width
48 inch(es) / 121.92 cm
Additional Dimensions
• Product Height (From Bottom To Top Of Back Splash): 36 1/8"-37 1/8"
• Product Height (From Bottom To Top Of Side Panel): 35-9/16"
• Product Depth (From Back Panel To Bullnose): 27-1/2"
• Product Depth (From Back Panel To Control Board): 26-3/8"
• Product Depth (From Back Panel To Side Panel Front): 24"
• Depth Of Control Panel (Minimum): 2-5/16"
• Depth Of Control Panel (Bullnose): 3-1/2"
• Adjustable Legs Not to Exceed: 1"
• Required Cutout Size: 48-1/8" X 25" X 34-7/8" (+1")
• Product Height (From Bottom To Top Of Side Panel): 35-9/16"
• Product Depth (From Back Panel To Bullnose): 27-1/2"
• Product Depth (From Back Panel To Control Board): 26-3/8"
• Product Depth (From Back Panel To Side Panel Front): 24"
• Depth Of Control Panel (Minimum): 2-5/16"
• Depth Of Control Panel (Bullnose): 3-1/2"
• Adjustable Legs Not to Exceed: 1"
• Required Cutout Size: 48-1/8" X 25" X 34-7/8" (+1")
