Features
EVEN-HEAT™ TRUE CONVECTION
Features a unique bow-tie design with heating element and fan that provide even airflow and consistent temperatures throughout the entire oven for crisp, flaky baked goods, juicy, evenly browned roasts and flavorful, caramelized vegetables.
FIT GUARANTEE
A promise to fit slide-in ranges designed for an existing cutout of 30" width, countertop depth of 24"-25", cabinet depth of 23"-24" and countertop height of 36".
AQUALIFT®
Cleans your oven in less than an hour without odors and at a temperature below 200°F. This innovative system combines low heat with water to release baked-on spills.
EASYCONVECT™ CONVERSION SYSTEM
Automatically adjusts conventional baking temperatures to their convection equivalents from the KitchenAid™ app, making it effortless to use convection with recipes of all kinds.
STEAM RACK
Offers the ability to provide additional moisture to the inside of the oven, enhancing cooking results.
GLASS TOUCH CONTROLS
Offer an intuitive, easy-to-use touch screen experience.
Additional Features
BAKING DRAWER
Adds more cooking options to the oven. The separate compartment allows you to keep warm, slow cook or bake at a different temperature and keep dishes warm.
SIDE TRIM ACCESSORY KIT
This optional accessory kit will cover damaged countertops and unfinished edges from an old slide- in range to make them beautiful again. Trim pieces come in black, white and stainless to seamlessly match your new range.
Specifications
General
Fuel Type
Dual Fuel - Natural Gas
Installation Type
Slide-in
Color
Stainless Steel
Manufacturer Color
Stainless Steel
Cooktop
Burners/Elements
5
Burners/Elements Output
• Left Front Burner Power : 19,000 BTU
• Left Rear Burner Power : 5,000 BTU
• Right Front Burner Power : 15,000 BTU
• Right Rear Burner Power : 9,200 BTU
• Center Rear Burner Power : 8,000 BTU
• Left Rear Burner Power : 5,000 BTU
• Right Front Burner Power : 15,000 BTU
• Right Rear Burner Power : 9,200 BTU
• Center Rear Burner Power : 8,000 BTU
Burners
Sealed
Oven
Capacity (cu. ft.)
7.1 cu. ft.
Number of Ovens
Single
Features
Convection
Yes
Delay Bake/Start
Yes
Digital Temperature Display
Yes
Oven Light
Yes
Self-Cleaning
Yes
Additional Information
• Even-Heat™ True Convection
• Steam Rack
• EasyConvect™ Conversion
• Aqualift®
• Side Trim Accessory Kit Optional
• Glass Touch Controls
• Selections : Baking Drawer Bake, Baking Drawer Keep Warm, Baking Drawer Slow Cook, Clock, Cook Time, Delay Start, Keep Warm Setting, Proofing, Steam Bake, Warm Zone
• ADA Height and Operation Compliant
• Steam Rack
• EasyConvect™ Conversion
• Aqualift®
• Side Trim Accessory Kit Optional
• Glass Touch Controls
• Selections : Baking Drawer Bake, Baking Drawer Keep Warm, Baking Drawer Slow Cook, Clock, Cook Time, Delay Start, Keep Warm Setting, Proofing, Steam Bake, Warm Zone
• ADA Height and Operation Compliant
Drawer Features
Baking
Yes
Electrical Information
Information
120/240V - 120/208V
Dimensions
Class Width
30"
Width
29.87 inch(es) / 75.88 cm
Height
36 inch(es) / 91.44 cm
Depth (Without Handles)
26.37 inch(es) / 66.99 cm
Depth (Including Handles)
28.87 inch(es) / 73.34 cm
Weight
233.01 lb(s) / 105.69 kg
Additional Dimensions
• 28 7/8" (73.3 cm) Max. Depth From Handle To Back Of Range
• 28 5/16" (71.9 cm) Max. Depth From Front Of Console To Back Of Range
• 36" (91.4 cm) Height To Top Of Cooktop Edge With Leveling Legs Screwed In All The Way* (range Can Be Raised Approximately 1" (2.5 cm) By Adjusting The Leveling Legs)
• 28 5/16" (71.9 cm) Max. Depth From Front Of Console To Back Of Range
• 36" (91.4 cm) Height To Top Of Cooktop Edge With Leveling Legs Screwed In All The Way* (range Can Be Raised Approximately 1" (2.5 cm) By Adjusting The Leveling Legs)
Shipping Dimensions
Width
31.5 inch(es) / 80.01 cm
Height
43.5 inch(es) / 110.49 cm
Depth
30.56 inch(es) / 77.63 cm
Weight
251 lb(s) / 113.85 kg
Warranty
Warranty
Limited 1-Year Parts and Labor
UPC
UPC#
883049330013
