Features
9"/6" POWER BOIL ELEMENT
A power boiler produces concentrated heat for rapid boiling in a flexible 9-inch/6-inch burner size, so you spend less time waiting and more time cooking
ADA COMPLIANT
Designed to be accessible and easy to open
SELF-CLEAN OVEN
A GE invention, the Self-Clean feature uses concentrated heat to remove baked-on splatters, eliminating the need for scrubbing or use of harsh chemicals.
DUAL-ELEMENT BAKE
Upper and lower elements produce even heat and great results.
BLACK GLOSS OVEN INTERIOR
Enjoy a clean and sleek appearance
Additional Features
CERAMIC GLASS COOKTOP
Smooth cooktop easily wipes clean.
ELECTRONIC OVEN CONTROLS
Electronic pads on the control panel are easy to operate with just a touch.
Specifications
General
Fuel Type
Electric
Installation Type
Drop-in
Color
White
Manufacturer Color
White
Appliance Care
Cooktop Cleaning: Cream Included Sponge
Cooktop
Burners/Elements
4
Burners/Elements Output
• Element - Left Front: 2000W
• Element - Left Rear: 2000W
• Element - Right Front: 3000W Power Boil
• Element - Right Rear: 1200W
• Element - Left Rear: 2000W
• Element - Right Front: 3000W Power Boil
• Element - Right Rear: 1200W
Burner/Element Size
• Element - Left Front: 8"
• Element - Left Rear: 8"
• Element - Right Front: 9"/6"
• Element - Right Rear: 6"
• Element - Left Rear: 8"
• Element - Right Front: 9"/6"
• Element - Right Rear: 6"
Elements
Smoothtop
Oven
Capacity (cu. ft.)
4.4 cu ft
Number of Ovens
Single
Features
Control Lock
Yes
Delay Bake/Start
Yes
Digital Temperature Display
Yes
Oven Light
Yes
Self-Cleaning
Yes
Additional Information
• Made in America: 70 to 90% U.S. Content
• Control Knobs: Color-Matched, Weighted
• Handle: Color-Matched, Designer Style
• Installation: Flush Appearance
• Oven Door Features: Big View Oven Window, Glass Door
• Control Location: Front
• Audible Preheat Signal
• Auto Oven Shut-Off with Override
• C° or F° Programmable
• Self-Clean Oven Door Lock: Automatic
• Control Type: Digital Temperature Display, Electronic, Touchpads
• Heating Element "ON" Indicator Light: 2
• Hot Surface Indicator Lights: 4
• Interior Oven Light: 1 Incandescent
• Oven Features: 6-Pass Bake Element, 6-Pass Broil Element
• Oven Rack Features: 2 Oven Racks, 7 Rack Positions
• Melt Setting: Yes
• Control Knobs: Color-Matched, Weighted
• Handle: Color-Matched, Designer Style
• Installation: Flush Appearance
• Oven Door Features: Big View Oven Window, Glass Door
• Control Location: Front
• Audible Preheat Signal
• Auto Oven Shut-Off with Override
• C° or F° Programmable
• Self-Clean Oven Door Lock: Automatic
• Control Type: Digital Temperature Display, Electronic, Touchpads
• Heating Element "ON" Indicator Light: 2
• Hot Surface Indicator Lights: 4
• Interior Oven Light: 1 Incandescent
• Oven Features: 6-Pass Bake Element, 6-Pass Broil Element
• Oven Rack Features: 2 Oven Racks, 7 Rack Positions
• Melt Setting: Yes
Electrical Information
Information
• Amp Rating at 208V: 40
• Amp Rating at 240V: 40
• Bake Wattage: 3410W
• Broiler Wattage: 3420W
• KW Rating at 208V: 8.9
• KW Rating at 240V: 11.9
• Amp Rating at 240V: 40
• Bake Wattage: 3410W
• Broiler Wattage: 3420W
• KW Rating at 208V: 8.9
• KW Rating at 240V: 11.9
Certifications and Approvals
ADA Compliant
Yes
Sabbath/Star-K
Yes
Information
Listed by Underwriters Laboratories
Dimensions
Class Width
30"
Width
31.25 inch(es) / 79.38 cm
Height
27 inch(es) / 68.58 cm
Depth (Without Handles)
25.75 inch(es) / 65.40 cm
Depth (Including Handles)
28.5 inch(es) / 72.39 cm
Weight
152.01 lb(s) / 68.95 kg
Additional Dimensions
• Cooktop Width: 31.25 in
• Cabinet Opening: 30.0 in
• Cabinet Width: 30.0 in
• Oven Interior Dimensions (W x H x D) (in.): 24 x 17-1/2 x 18-1/4
• Depth with Door Open: 44.625 in
• Cabinet Opening: 30.0 in
• Cabinet Width: 30.0 in
• Oven Interior Dimensions (W x H x D) (in.): 24 x 17-1/2 x 18-1/4
• Depth with Door Open: 44.625 in
Shipping Dimensions
Width
30.8 inch(es) / 78.23 cm
Height
39.5 inch(es) / 100.33 cm
Depth
33.5 inch(es) / 85.09 cm
Weight
178.99 lb(s) / 81.19 kg
Warranty
Warranty
• Parts Warranty: Limited 1-year entire appliance
• Labor Warranty: Limited 1-year entire appliance
• Labor Warranty: Limited 1-year entire appliance
UPC
UPC#
084691909415
