Specifications
General
Series Name
Galiano
Fuel Type
Natural Gas
Installation Type
Freestanding
Color
Stainless Steel
Manufacturer Color
Stainless Steel
Cooktop
Burners/Elements
5
Burners/Elements Output
• Total Stovetop BTU / Watts: 68,000 BTU
• Middle Burner: 20,000 BTU
• Front Right Burner: 15,000 BTU
• Front Left Burner: 15,000 BTU
• Rear Right Burner: 9,000 BTU
• Rear Left Burner: 9,000 BTU
• Middle Burner: 20,000 BTU
• Front Right Burner: 15,000 BTU
• Front Left Burner: 15,000 BTU
• Rear Right Burner: 9,000 BTU
• Rear Left Burner: 9,000 BTU
Burners
Sealed
Oven
Capacity (cu. ft.)
4.32 cu. ft.
Number of Ovens
Single
Features
Technologies
Convection Technology
Convection
Yes
Oven Light
Yes
Additional Information
• French door design
• 1 sealed dual-ring burner for high searing or precise simmering
• Black Enamel Cooktop
• Continuous Cast Iron Grates provide even heat distribution and stable cookware mobility
• Convection Fan Oven with 30,000 BTU Total Broil and Bake output
• Black enamel oven cavity with two halogen lights in each oven
• Adjustable Stainless Steel Legs Accommodate Counter Heights between 36" to 37"
• 1 sealed dual-ring burner for high searing or precise simmering
• Black Enamel Cooktop
• Continuous Cast Iron Grates provide even heat distribution and stable cookware mobility
• Convection Fan Oven with 30,000 BTU Total Broil and Bake output
• Black enamel oven cavity with two halogen lights in each oven
• Adjustable Stainless Steel Legs Accommodate Counter Heights between 36" to 37"
Electrical Information
Information
• 15 Amps
• 120 Volts
• 3-Prong Grounded
• 120 Volts
• 3-Prong Grounded
Certifications and Approvals
Information
ETL Listed
Accessories
Included
• Includes 2 Electro-Plated Oven Racks with 7.5mm frame and 4mm grid, LP Conversion Kit and 3-Prong Plug.
• Adjustable Stainless Steel Legs Accommodate Counter Heights between 35.5" to 36.5"
• Adjustable Stainless Steel Legs Accommodate Counter Heights between 35.5" to 36.5"
Dimensions
Class Width
30"
Width
30 inch(es) / 76.2 cm
Height
37.6 inch(es) / 95.5 cm
Depth (Without Handles)
28.54 inch(es) / 72.49 cm
Weight
234.13 lb(s) / 106.2 kg
Additional Dimensions
• Cutout dimensions W x D x H (inch): 30 x 25 x 36
• Main Oven Usable Interior (W x D x H): 24 x 15 x 10.38
• Main Oven Usable Interior (W x D x H): 24 x 15 x 10.38
Warranty
Warranty
Limited 2-Year
UPC
UPC#
686136964043
