Specifications
General
Fuel Type
Dual Fuel - Natural Gas
Installation Type
Freestanding
Color
Stainless Steel
Manufacturer Color
Stainless Steel
Appliance Care
Steam
Cooktop
Burners/Elements
6
Burners/Elements Output
• Total Stovetop BTU / Watts: 120,000 BTU
• Front Right Burner: 1000 BTU to 20,000 BTU
• Front Center Burner: 1000 BTU to 20,000 BTU
• Front Left Burner: 1000 BTU to 20,000 BTU
• Rear Right Burner: 1000 BTU to 20,000 BTU
• Rear Center Burner: 1000 BTU to 20,000 BTU
• Rear Left Burner: 1000 BTU to 20,000 BTU
• Front Right Burner: 1000 BTU to 20,000 BTU
• Front Center Burner: 1000 BTU to 20,000 BTU
• Front Left Burner: 1000 BTU to 20,000 BTU
• Rear Right Burner: 1000 BTU to 20,000 BTU
• Rear Center Burner: 1000 BTU to 20,000 BTU
• Rear Left Burner: 1000 BTU to 20,000 BTU
Burners
Sealed
Other
Wok
Oven
Capacity (cu. ft.)
5.36 Cubic Feet
Number of Ovens
Single
Features
Technologies
True Convection
Air Fry
Yes
Convection
Yes
Oven Light
Yes
Additional Information
• Sealed Dual-Ring Brass Burners
• Black Enamel Cooktop
• Heavy-Duty Continuous Cast Iron Grates
• Brass Burners 20K BTU high with simmer
• Black Enamel Cooktop
• Heavy-Duty Continuous Cast Iron Grates
• Brass Burners 20K BTU high with simmer
Electrical Information
Information
• 30 Amps
• 240 Volts
• 6300 Watts
• 4-Prong Grounded
• 240 Volts
• 6300 Watts
• 4-Prong Grounded
Certifications and Approvals
Information
ETL Listed
Accessories
Included
• Includes 3 Heavy-Duty Stainless Steel Telescopic Oven Racks, Air Fryer Basket, Rack & Drip Pan, Rotisserie Kit with Skewer Forks, LP Conversion Kit and 4-Prong Plug.
• Adjustable Stainless Steel Legs Accommodate Counter Heights between 35.5" to 36.5"
• LP Kit Included
• Wok-Ring
• Reversible Grill/Griddle
• Rotisserie Kit
• Adjustable Stainless Steel Legs Accommodate Counter Heights between 35.5" to 36.5"
• LP Kit Included
• Wok-Ring
• Reversible Grill/Griddle
• Rotisserie Kit
Dimensions
Class Width
36"
Width
36 inch(es) / 91.44 cm
Height
37.4 inch(es) / 95 cm
Depth (Without Handles)
28 inch(es) / 71.12 cm
Weight
337.31 lb(s) / 153 kg
Additional Dimensions
• Power Cord Length: 5 feet
• Minimum Counter Height (IN): 35.5
• Minimum Counter Height (CM): 90.17
• Maximum Counter Height (IN): 36.5
• Maximum Counter Height (CM): 92.71
• Depth with Oven Door Open 90º (IN): 41.5
• Depth with Oven Door Open 90º (CM): 105.41
• Oven Interior Width (IN): 30.92
• Oven Interior Depth (CM): 78.5368
• Oven Interior Depth (IN): 18.7
• Oven Interior Depth (CM): 47.498
• Oven Interior Height (IN): 16
• Oven Interior Height (CM): 40.64
• Minimum Counter Height (IN): 35.5
• Minimum Counter Height (CM): 90.17
• Maximum Counter Height (IN): 36.5
• Maximum Counter Height (CM): 92.71
• Depth with Oven Door Open 90º (IN): 41.5
• Depth with Oven Door Open 90º (CM): 105.41
• Oven Interior Width (IN): 30.92
• Oven Interior Depth (CM): 78.5368
• Oven Interior Depth (IN): 18.7
• Oven Interior Depth (CM): 47.498
• Oven Interior Height (IN): 16
• Oven Interior Height (CM): 40.64
Shipping Dimensions
Width
38.39 inch(es) / 97.51 cm
Height
43.58 inch(es) / 110.69 cm
Depth
30.75 inch(es) / 78.11 cm
Weight
373.99 lb(s) / 169.64 kg
Warranty
Warranty
Limited 2-Year Warrenty on Parts and Labor
UPC
UPC#
686136963091
