Specifications
General
Series Name
Alta Qualita
Fuel Type
Natural Gas
Installation Type
Freestanding
Color
Stainless Steel
Appliance Care
Steam Clean
Cooktop
Burners/Elements
8
Burners/Elements Output
• Front Right Sealed Dual Burner BTU(Brass): 20,000 /Sim 1,000 BTU
• Front Left-Center Sealed Burner BTU: 15,000
• Front Right-Center Sealed Burner BTU: 15,000
• Front Left Sealed Burner BTU: 15,000
• Rear Left Sealed Burner BTU: 9,000
• Rear Left-Center Sealed Burner BTU: 9,000
• Rear Right-Center Sealed Burner BTU: 9,000
• Rear Right Sealed Burner BTU: 15,000
• Front Left-Center Sealed Burner BTU: 15,000
• Front Right-Center Sealed Burner BTU: 15,000
• Front Left Sealed Burner BTU: 15,000
• Rear Left Sealed Burner BTU: 9,000
• Rear Left-Center Sealed Burner BTU: 9,000
• Rear Right-Center Sealed Burner BTU: 9,000
• Rear Right Sealed Burner BTU: 15,000
Burners
Sealed
Other
Wok
Oven
Capacity (cu. ft.)
• Total Capacity: 6.58 cu. ft.
• Large Oven: 4.32 cu. ft.
• Small Oven: 2.26 cu. ft.
• Large Oven: 4.32 cu. ft.
• Small Oven: 2.26 cu. ft.
Number of Ovens
Double
Features
Technologies
Convection Technology
Convection
Yes
Oven Light
Yes
Additional Information
• Cast Iron Grates
• Wok Ring
• Reversible Girll/Griddle
• Black Enameled Cooktop
• On/Off Button Controlled Night Light Red LED
• Convection Fan On/Off Button
• Die Cast Metal Illuminated and Zince Coated Knobs with Bezels
• Blue Enameled Oven Interior
• Pro-Style Handles
• 30" Oven Two Halogen Oven Lights
• 18" Oven One Halogen Oven Light
• Air Fry Rack, Basket and Drip Pan
• Each Oven: Two 304 SS Full Extension Telescopic Racks
• Automatic Ignition and Re-ignition
• Front of Range Adjusts to meet standard 36" counter
• 30" Broil 10,000 BTU and Bake 22,000 BTU
• 18" Bake 14,000 BTU
• Wok Ring
• Reversible Girll/Griddle
• Black Enameled Cooktop
• On/Off Button Controlled Night Light Red LED
• Convection Fan On/Off Button
• Die Cast Metal Illuminated and Zince Coated Knobs with Bezels
• Blue Enameled Oven Interior
• Pro-Style Handles
• 30" Oven Two Halogen Oven Lights
• 18" Oven One Halogen Oven Light
• Air Fry Rack, Basket and Drip Pan
• Each Oven: Two 304 SS Full Extension Telescopic Racks
• Automatic Ignition and Re-ignition
• Front of Range Adjusts to meet standard 36" counter
• 30" Broil 10,000 BTU and Bake 22,000 BTU
• 18" Bake 14,000 BTU
Electrical Information
Information
120 V, 60 Hz,15 A
Accessories
Included
LP Kit
Dimensions
Class Width
48"
Width
48 inch(es) / 121.92 cm
Height
35.4 inch(es) / 89.92 cm
Depth (Without Handles)
28 inch(es) / 71.12 cm
Weight
366.01 lb(s) / 166.02 kg
Shipping Dimensions
Width
50.9 inch(es) / 129.29 cm
Height
43.58 inch(es) / 110.69 cm
Depth
30.39 inch(es) / 77.19 cm
Weight
386.01 lb(s) / 175.09 kg
