Features
9100 BTU BURNERS
Provide enough space to cook multiple dishes simultaneously.
GENEROUS BACKSPLASH
The generous backsplash protects the wall against spills.
BROILER DRAWER
Broiler drawer includes a spring-loaded hinge that closes the drawer automatically.
LIQUID PROPANE CONVERSION KIT
Liquid Propane conversion kit included; enables the range to run on liquid propane, making it a great cooking option for remote locations.
ADJUSTABLE LEGS
Four adjustable legs for a custom fit to the height of your counter.
Specifications
General
Series Name
Designer Series
Fuel Type
Natural Gas
Installation Type
Freestanding
Color
White
Manufacturer Color
White
Cooktop
Burners/Elements
4
Burners/Elements Output
• Four 9,100 BTU open burners
• One 13,000 BTU oven burner
• One 13,000 BTU oven burner
Burners
Open
Oven
Capacity (cu. ft.)
3.0 cu. ft.
Number of Ovens
Single
Features
Control Lock
No
Convection
No
Delay Bake/Start
No
Digital Temperature Display
No
Downdraft Ventilation
No
Oven Light
Yes
Self-Cleaning
Yes
Additional Information
• Electronic ignition
• Easy-clean, lift-up porcelain cooktop
• Front-mount push and turn safety knobs
• Two oven racks with four adjustable positions and safety stops for optimal cooking
• Broiler drawer includes a spring-loaded hinge that closes the drawer automatically
• Four adjustable legs for a custom fit to the height of your counter
• Three-piece broiler pan included
• Oven temperature range of 250°F-500°F
• Manual clean range
• Liquid Propane conversion kit included
• Easy-clean, lift-up porcelain cooktop
• Front-mount push and turn safety knobs
• Two oven racks with four adjustable positions and safety stops for optimal cooking
• Broiler drawer includes a spring-loaded hinge that closes the drawer automatically
• Four adjustable legs for a custom fit to the height of your counter
• Three-piece broiler pan included
• Oven temperature range of 250°F-500°F
• Manual clean range
• Liquid Propane conversion kit included
Drawer Features
Baking
No
Broiler
Yes
Storage
Yes
Warming
No
Electrical Information
Information
120 volts
Certifications and Approvals
Sabbath/Star-K
No
Dimensions
Class Width
24"
Width
24 inch(es) / 60.96 cm
Height
43 inch(es) / 109.22 cm
Depth (Without Handles)
26 inch(es) / 66.04 cm
Shipping Dimensions
Weight
143.96 lb(s) / 65.3 kg
Warranty
Warranty
18 months parts and labor coverage with In-Home service. Installation and/or Yearly Maintenance (cleaning) are not covered under warranty.
UPC
UPC#
676389997936
